Description
Usage
Insert brackets are used to insert wood posts (i.e. a 4×4) in between 2 existing wood posts such that the 4x4s are inline and “flush” with the posts. These brackets are extremely versatile and can be used in all of the following ways:
- Inline 4×4 roof rafter kit
- 4×4 privacy wall
- Side railings (various styles)
The brackets are open at the top so the 4×4 wood post can be inserted from above after you’ve secured the brackets to the existing posts.
4×4 Pergola Bracket Features
- Made with premium quality steel
- 14-gauge steel (~2.0mm thick)
- Made for dressed lumber commonly called 4x4s (actual dimensions are 3.5” x 3.5”)
- Laser-cut, bent and welded
- Advanced weather coating technology to withstand extreme weather conditions
- Pre-drilled holes for securing wood and accessories to bracket
- Includes stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into bracket
- Reduces your pergola build time by as much as 75%
- Backed by a 5-year warranty
- Shipped directly to your doorstep from Boise, Idaho
Dimensions & Specifications
- Width: 3.75 inches (95 mm)
- Depth: 2.0 inches (51 mm)
- Height: 3.55 inches (90.5 mm)
- Inner dimensions of sleeve (open at top): 3.6 x 3.5 inches (92 x 88.5 mm) – made for 4×4 wood posts (which measure 3.5 x 3.5 inches)
- Holes on end plate (secured to post/beam): 4 (one in each corner)
- Holes on each side wall: 4 (one in each corner)
- Hole size: 0.25 inch (6.35 mm) – ideal for #10 size screws (included)
- Weight: 1.0 pound
- Not included: wood posts
